Cobot Omron Tm12s Workstation

Community design

Mikron

Spec Attribute	Spec Value
Technical Specifications
Design Number	MF-RB-348478
Weight	198.00 kg
Dimensions (L x W x H)	1202 x 1892 x 2006 mm
Application	Manufacturing
Assembly Time	15:20

Spec Attribute	Spec Value
Documentation
Assembly Instructions
ROI Calculator
3D Model

Parts	Description	Quantity
Parts		Qty
	Ergonomic HandleHW-HD-001-0001__2 - 160 X 30 X 60 mmShips next day	5
	Spring-Loaded Grab CatchHW-LT-002-0001__2 - 90 X 90 X 19 mmShips in 3 days	2
	45x90mm Rest PadHW-RP-002-0001 - 13 X 90 X 45 mmShips next day	2
	90x90mm Rest PadHW-RP-002-0006 - 90 X 90 X 13 mmShips next day	2
	Screw-in Cable Tie MountHW-TW-001-0001 - 38 X 23 X 13 mmShips in 17 days	12
	Blickle Swivel Leveling Caster Wheel with Adjustment Wheel, 500kg CapacityMO-WL-003-0002 - 125 X 90 X 104 mmShips next day	4
	Panel Sliding DoorST-DR-001-0001 - 675 X 22 X 697 mmShips next day	2
	45x90mm (675mm) Aluminum ExtrusionST-EXT-002-0675 - 675 X 45 X 90 mmShips next day	2
	45x90mm (1710mm) Aluminum ExtrusionST-EXT-002-1710 - 1710 X 45 X 90 mmShips next day	1
	45x90mm (1800mm) Aluminum ExtrusionST-EXT-002-1800 - 1800 X 45 X 90 mmShips next day	7
	45x45mm (585mm) Light Aluminum ExtrusionST-EXT-101-0585 - 585 X 45 X 45 mmShips next day	2
	45x45mm (720mm) Light Aluminum ExtrusionST-EXT-101-0720 - 720 X 45 X 45 mmShips next day	8
	45x45mm (810mm) Light Aluminum ExtrusionST-EXT-101-0810 - 810 X 45 X 45 mmShips next day	7
	45x45mm (855mm) Light Aluminum ExtrusionST-EXT-101-0855 - 855 X 45 X 45 mmShips next day	2
	45x45mm (900mm) Light Aluminum ExtrusionST-EXT-101-0900 - 900 X 45 X 45 mmShips next day	2
	45x45mm (945mm) Light Aluminum ExtrusionST-EXT-101-0945 - 945 X 45 X 45 mmShips next day	6
	45x45mm (990mm) Light Aluminum ExtrusionST-EXT-101-0990 - 990 X 45 X 45 mmShips next day	2
	45x45mm (1080mm) Light Aluminum ExtrusionST-EXT-101-1080 - 1080 X 45 X 45 mmShips next day	3
	45x45mm (1710mm) Light Aluminum ExtrusionST-EXT-101-1710 - 1710 X 45 X 45 mmShips next day	5
	45x45mm (1800mm) Light Aluminum ExtrusionST-EXT-101-1800 - 1800 X 45 X 45 mmShips next day	4
	2x4 Hole Aluminum Assembly PlateST-GP-001-0002 - 88 X 178 X 6 mmShips next day	7
	L-Shaped Aluminum Assembly Plate, for 45 x 45mm ExtrusionsST-GP-001-0005 - 133 X 133 X 6 mmShips next day	12
	1x3 Hole Aluminum Assembly PlateST-GP-001-0007 - 6 X 43 X 133 mmShips next day	2
	2x3 Hole Aluminum Assembly PlateST-GP-001-0008 - 6 X 88 X 133 mmShips next day	2
	90 Degree Joint Aluminum Assembly Plate, for 45x45mm ExtrusionsST-GP-001-0009 - 6 X 133 X 133 mmShips in 10 days	6
	90 Degree Joint Aluminum Assembly Plate, for 45x90mm ExtrusionsST-GP-001-0010 - 6 X 178 X 178 mmShips next day	2
	90 Deg Joint Assembly Plate, for 45 x 45mm to 45 x 90mm ExtrusionsST-GP-001-0013 - 6 X 133 X 178 mmShips next day	4
	2x5 Hole Aluminum Assembly PlateST-GP-001-0019 - 223 X 88 X 6 mmShips next day	2
	45mm x 45mm Aluminum GussetST-GP-003-0001 - 42 X 44 X 44 mmShips next day	2
	Two-Way Extended Door ConnectorST-GP-004-0006__2 - 83 X 45 X 45 mmShips next day	12
	45mm x 45mm Aluminum Gusset with LocatorsST-HP-003-0001 - 42 X 44 X 44 mmShips next day	22
	Panel strip for 5.6 mm (0.22 in) panels - 1 mST-PN-014-0003 - 1000 X 6 X 13 mmShips next day	13
	TM12 & TM14 Mounting PlateST-RB-014-0002 - 225 X 225 X 29 mmShips in 3 days	1
	Door HingeST-SE-005-0001 - 67 X 67 X 19 mmShips next day	6
	Premium Caster Wheel Mounting Plate for MO-WL-003-0002ST-SP-010-0002 - 90 X 90 X 11 mmObsolete	4
	HDPE Panel, Black 1/4'' [6.35mm]ST-PN-001-0004__2 - 0.5463 m²Ships in 4 days	1
	HDPE Panel, Black 1/4'' [6.35mm]ST-PN-001-0004__2 - 0.5463 m²Ships in 4 days	1
	HDPE Panel, Black 1/4'' [6.35mm]ST-PN-001-0004__2 - 1.1355 m²Ships in 4 days	1
	HDPE Panel, Black 1/4'' [6.35mm]ST-PN-001-0004__2 - 0.3270 m²Ships in 4 days	1
	HDPE Panel, Black 1/8'' [3.18mm]ST-PN-001-0007 - 1.6160 m²Ships in 4 days	1
	Polycarbonate Panel, Clear 0.22'' [5.6mm]ST-PN-004-0001__2 - 0.7885 m²Ships in 4 days	1
	Polycarbonate Panel, Clear 0.22'' [5.6mm]ST-PN-004-0001__2 - 0.7885 m²Ships in 4 days	1
	Polycarbonate Panel, Clear 0.22'' [5.6mm]ST-PN-004-0001__2 - 0.8792 m²Ships in 4 days	1
	Polycarbonate Panel, Clear 0.22'' [5.6mm]ST-PN-004-0001__2 - 0.2632 m²Ships in 4 days	1
	Polycarbonate Panel, Clear 0.22'' [5.6mm]ST-PN-004-0001__2 - 1.2109 m²Ships in 4 days	1
	M8 Drop-in Spring Loaded T-NutHW-FN-002-0001 - 22 X 13 X 7 mmShips next day	455
	M8 x 14mm ScrewHW-FN-003-0014 - 19 X 13 X 13 mmShips next day	26
	M8 x 16mm ScrewHW-FN-003-0016 - 16 X 13 X 21 mmShips next day	26
	M8 x 18mm ScrewHW-FN-003-0018 - 23 X 13 X 13 mmShips next day	367
	M8 x 20mm ScrewHW-FN-003-0020 - 25 X 13 X 13 mmShips next day	19
	M8 x 25mm ScrewHW-FN-003-0025 - 30 X 13 X 13 mmShips next day	9
	M8 x 50mm ScrewHW-FN-003-0050 - 55 X 13 X 13 mmShips next day	26
	M8 1.25 x 16mm Flat Head ScrewHW-FN-015-0016 - 16 X 16 X 16 mmShips in 18 days	27
	M8 Washer with 16mm Outside DiameterHW-WS-001-0001 - 1 X 16 X 16 mmShips next day	19
	M8 Washer with 24mm Outside DiameterHW-WS-001-0002 - 2 X 24 X 24 mmShips next day	15
	5mm x 250mm Cable Tie (Bag of 25)HW-TW-002-0001 - 250 X 5 X 4 mmShips next day	1
	Panel RetainersST-PN-007-0001 - 23 X 45 X 87 mmShips next day	14
