TFF Cart with SS shelves

Community design

A compact, 4-shelf cart designed to hold two heavy pumps on the bottom shelves, a membrane cassette holder or reaction vessel on the topmost large shelf and an upper shelf to hold the controls and associated electronics.

Spec Attribute	Spec Value
Technical Specifications
Design Number	MH-IC-463097
Weight	118.60 kg
Dimensions (L x W x H)	1055 x 765 x 2181 mm
Application	Material Handling
Assembly Time	07:32

Spec Attribute	Spec Value
Documentation
Assembly Instructions
ROI Calculator
3D Model

Parts	Description	Quantity
Parts		Qty
	Rubber BumperHW-BP-001-0002 - 50 X 80 X 43 mmShips next day	6
	Slotted Wiring DuctHW-CA-006-2000 - 2000 X 40 X 50 mmShips next day	2
	45x45mm Plastic End Cap, for ExtrusionsHW-EC-001-0001__2 - 12 X 45 X 45 mmShips next day	8
	Ergonomic HandleHW-HD-001-0001__2 - 160 X 30 X 60 mmShips next day	2
	Blickle Swivel Caster Wheel with Brake, 150kg CapacityMO-WL-001-0004 - 160 X 85 X 125 mmShips next day	4
	45x45mm (585mm) Aluminum ExtrusionST-EXT-001-0585 - 585 X 45 X 45 mmShips in 2 days	12
	45x45mm (855mm) Aluminum ExtrusionST-EXT-001-0855 - 855 X 45 X 45 mmShips in 2 days	7
	45x45mm (900mm) Aluminum ExtrusionST-EXT-001-0900 - 900 X 45 X 45 mmShips in 2 days	4
	45x45mm (1530mm) Aluminum ExtrusionST-EXT-001-1530 - 1530 X 45 X 45 mmShips in 2 days	2
	L-Shaped Aluminum Assembly Plate, for 45 x 45mm ExtrusionsST-GP-001-0005 - 133 X 133 X 6 mmShips next day	2
	90 Degree Joint Aluminum Assembly Plate, for 45x45mm ExtrusionsST-GP-001-0009 - 6 X 133 X 133 mmShips next day	2
	Tee Joint Aluminum Assembly Plate, for 45 x 45mm ExtrusionST-GP-001-0015 - 6 X 133 X 133 mmShips next day	2
	45mm x 45mm Aluminum GussetST-GP-003-0001 - 42 X 44 X 44 mmShips in 2 days	1
	45mm x 45mm Aluminum Gusset with LocatorsST-HP-003-0001 - 42 X 44 X 44 mmShips next day	64
	45 Degree Inline Connector with LocatorsST-HP-003-0003__2 - 45 X 45 X 5 mmShips next day	4
	Locating Fixture with Quick Release PinST-SP-009-0002__2 - 43 X 88 X 142 mmShips next day	2
	Premium Caster Wheel Mounting PlateST-SP-010-0001 - 100 X 90 X 11 mmShips next day	4
	Stainless Steel Panel, 11 Ga. [3.13mm]ST-PN-018-0001 - 0.6379 m²Ships in 5 days	1
	Stainless Steel Panel, 11 Ga. [3.13mm]ST-PN-018-0001 - 0.6379 m²Ships in 5 days	1
	Stainless Steel Panel, 11 Ga. [3.13mm]ST-PN-018-0001 - 0.4253 m²Ships in 5 days	1
	Stainless Steel Panel, 11 Ga. [3.13mm]ST-PN-018-0001 - 0.6379 m²Ships in 5 days	1
	M8 Drop-in Spring Loaded T-NutHW-FN-002-0001 - 22 X 13 X 7 mmShips next day	265
	M6 Drop-in Spring Loaded T-NutHW-FN-002-0004 - 22 X 13 X 9 mmShips next day	26
	M8 x 14mm ScrewHW-FN-003-0014 - 19 X 13 X 13 mmShips next day	52
	M8 x 18mm ScrewHW-FN-003-0018 - 23 X 13 X 13 mmShips next day	202
	M8 x 20mm ScrewHW-FN-003-0020 - 25 X 13 X 13 mmShips next day	5
	M8 x 50mm ScrewHW-FN-003-0050 - 55 X 13 X 13 mmShips next day	9
	M6 x 1.0 x 16mm, Low Profile Socket HeadHW-FN-005-0016 - 20 X 10 X 10 mmShips next day	26
	M8 X1.25 Zinc Plated Thin Hex NutHW-FN-033-0002 - 13 X 13 X 4 mmShips next day	13
	M8 Washer with 16mm Outside DiameterHW-WS-001-0001 - 1 X 16 X 16 mmShips next day	17
	M6 Oversized Washer with 18mm Outside DiameterHW-WS-005-0002 - 1 X 18 X 18 mmShips next day	26
