HW-LT-001-0001
Spring-Loaded Grab Latch
Nylon grab latch with two spring-loaded balls to securely hold the door in position.
| Technical Drawing | |
|---|---|
| Technical Drawing | |
| 2D Model | |
| 3D Model |
Can't find what you're looking for? Contact Us
| Spec Attribute | Spec Value |
|---|---|
| General Specifications | |
| Part Number | HW-LT-001-0001 |
| Unit Price | $13.08 USD |
| Weight | 0.04 kg |
| Dimensions (L x W x H) | 75 x 74 x 15 mm |
| Material | Nylon |
| Surface Finish | N/A |
| Standards | Spring-ball catch |
| Associated Fasteners | 2 x HW-FN-002-0001, 2 x HW-FN-003-0020 |
| Light Duty Fasteners | 2 x HW-FN-002-0001, 2 x HW-FN-003-0012 |
