Robot 7th axis - Overhead Rack and Pinion Actuator

Robot 7th axis - Overhead Rack and Pinion Actuator

By: User badge
$30,604.93 USD
Vention robot transfer unit compatible with Fanuc, Universal Robots and More. Driven by a modular rack and pinion actuator supported by a t-slot aluminum structure. Robot arm not included.

0 comments
View in 3D
Use desktop to open this design in the MachineBuilder
Not all parts available

Not sure where to start?

Get help from an expert

Technical Specifications

Spec Attribute Spec Value
Design number MF-EX-356783 v5
Weight 296.8 kg
Dimensions (L x W x H) 523 x 3604 x 2703 mm
Unit price $30,604.93 USD
Use case Manufacturing
Application Robot 7th Axis
Assembly time 15:52

Supporting Documents

Technical Drawings

Technical Documents

Calculators

Technical Specifications

Spec Attribute Spec Value
Design number MF-EX-356783 v5
Weight 296.8 kg
Dimensions (L x W x H) 523 x 3604 x 2703 mm
Unit price $30,604.93 USD
Use case Manufacturing
Application Robot 7th Axis
Assembly time 15:52
