Heavy-duty XYZ Gantry

Heavy-duty XYZ Gantry
MachineLogic Code-Free

Heavy-duty XYZ Gantry

By: User badge
$62,439.30 USD
High-performance large XYZ gantry system made with 4 Vention enclosed timing belt actuators (X and Y axis) and 1 rack and pinion actuator (Z-axis). Ideal for applications that requires 3D motion such as palletizing or glue dispensing. Includes MachineMotion 2 controller, pendant, motors, sensors, and cabling. Programming is done via code-free MachineLogic interface or via Python. Automated designs should be reviewed by an engineer for performance, suitability and risk assessment of the overall system. Reach out to support@vention.io to ensure the gantry and controls are suited for your application.

0 comments
View in 3D
Contact Us
Use desktop to open this design in the MachineBuilder
All parts available

Not sure where to start?

Get help from an expert

Technical Specifications

Spec Attribute Spec Value
Design number MF-PF-132287 v23
Weight 372.4 kg
Dimensions (L x W x H) 3255 x 2630 x 2673 mm
Unit price $62,439.30 USD
Use case Manufacturing
Application Gantry Systems & Path Following
Assembly time 22:20
