FDM Printer Enclosure 4

Community design

Medium-duty enclosure for FDM printers that fit within a 600mm cube, designed to house 6mm thick rectangular panels sealed with rubber panel gasket (80/20 Inc. part no. 40-2115) and use rubber door seal (80/20 Inc. part no. 2829).

Spec Attribute	Spec Value
Technical Specifications
Design Number	MF-SF-51430
Weight	47.35 kg
Dimensions (L x W x H)	766 x 818 x 776 mm
Application	Manufacturing
Assembly Time	05:25

Spec Attribute	Spec Value
Documentation
Assembly Instructions
ROI Calculator
3D Model

Parts	Description	Quantity
Parts		Qty
	Rubber BumperHW-BP-001-0002 - 50 X 80 X 43 mmShips next day	4
	45x45mm Plastic End Cap, for ExtrusionsHW-EC-001-0001__2 - 12 X 45 X 45 mmShips next day	4
	Die-cast Aluminum HandleHW-HD-001-0001 - 140 X 25 X 40 mmObsolete	1
	Spring-Loaded Grab LatchHW-LT-001-0001 - 75 X 74 X 15 mmObsolete	1
	45x45mm Hinge, 8mm PinMO-HG-001-0001 - 27 X 80 X 40 mmShips next day	2
	45x45mm (540mm) Aluminum ExtrusionST-EXT-001-0540 - 540 X 45 X 45 mmShips in 4 days	2
	45x45mm (630mm) Aluminum ExtrusionST-EXT-001-0630 - 630 X 45 X 45 mmShips in 4 days	6
	45x45mm (720mm) Aluminum ExtrusionST-EXT-001-0720 - 720 X 45 X 45 mmShips in 4 days	2
	45x45mm (810mm) Aluminum ExtrusionST-EXT-001-0810 - 810 X 45 X 45 mmShips in 4 days	2
	45x90mm (630mm) Aluminum ExtrusionST-EXT-002-0630 - 630 X 45 X 90 mmShips next day	4
	L-Shaped Aluminum Assembly Plate, for 45 x 45mm ExtrusionsST-GP-001-0005 - 133 X 133 X 6 mmShips next day	24
	90 Degree Joint Aluminum Assembly Plate, with LocatorsST-HP-001-0001 - 6 X 133 X 133 mmShips next day	4
	45mm x 45mm Aluminum Gusset with LocatorsST-HP-003-0001 - 42 X 44 X 44 mmShips next day	4
	HDPE Panel, White 1/4'' [6.35mm]ST-PN-001-0003 - 0.4330 m²Obsolete	1
	Acrylic Panel, Clear 1/4'' [6.35mm]ST-PN-008-0001 - 0.3737 m²Obsolete	1
	Acrylic Panel, Clear 1/4'' [6.35mm]ST-PN-008-0001 - 0.4330 m²Obsolete	1
	Acrylic Panel, Clear 1/4'' [6.35mm]ST-PN-008-0001 - 0.3737 m²Obsolete	1
	Acrylic Panel, Clear 1/4'' [6.35mm]ST-PN-008-0001 - 0.4330 m²Obsolete	1
	Acrylic Panel, Clear 1/4'' [6.35mm]ST-PN-008-0001 - 0.3226 m²Obsolete	1
	M8 Drop-in Spring Loaded T-NutHW-FN-002-0001 - 22 X 13 X 7 mmShips next day	165
	M8 x 18mm ScrewHW-FN-003-0018 - 23 X 13 X 13 mmShips next day	163
	M8 x 20mm ScrewHW-FN-003-0020 - 25 X 13 X 13 mmShips next day	3
	M8 X1.25 Zinc Plated Thin Hex NutHW-FN-033-0002 - 13 X 13 X 4 mmShips next day	9
	M8 Washer with 16mm Outside DiameterHW-WS-001-0001 - 1 X 16 X 16 mmShips next day	9
